LIQUID PENETRATION INSPECTION
www.pis.edu.my
Principles of liquid penetrant inspection
1. Steps for liquid penetrant
2. Common users for liquid penetrant
1. Surface preparation The penetrant is left on the
3. Advantages and disadvantages
2. Penetrant application surface for a sufficient time to
3. Penetrant dwelling time allow as much penetrant as
4. Excess penetrant removal possible to be drawn from or to
5. Developer application seep into a defect.
6. Indication development
7. Inspection Penetrant dwell time is the total
8. Clean surface time that the penetrant is in
contact with the part surface.
