Drawing Command:
Polyline
COMMAND WINDOW
Command: _pline
Specify start point:
Specify next point or [Arc/Halfwidth/Length/Undo/Width]: H
Specify starting half-width <2.5000>:
Specify ending half-width <2.5000>:
Specify next point or [Arc/Halfwidth/Length/Undo/Width]: L
Specify next point or [Arc/Halfwidth/Length/Undo/Width]: 70
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: A
Specify endpoint of arc (hold Ctrl to switch direction) or
[Angle/CEnter/CLose/Direction/Halfwidth/Line/Radius/Second
pt/Undo/Width]:
Specify endpoint of arc (hold Ctrl to switch direction) or
[Angle/CEnter/CLose/Direction/Halfwidth/Line/Radius/Second
pt/Undo/Width]: L
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]:
Specify next point or [Arc/Close/Halfwidth/Length/Undo/Width]: A
Specify endpoint of arc (hold Ctrl to switch direction) or
[Angle/CEnter/CLose/Direction/Halfwidth/Line/Radius/Second
pt/Undo/Width]:
Specify endpoint of arc (hold Ctrl to switch direction) or
[Angle/CEnter/CLose/Direction/Halfwidth/Line/Radius/Second
pt/Undo/Width]:
Combination - Line & Arc
